Getting Started¶
This is the Hand-Sanitizer Getting started page.
Project materials¶
IR distance sensor
TIP32C Transistor
1 kOhm resistor
DC submersible pump + tubing
4 AA battery pack
8.2 oz pour spout bag
PLA filament
Production Dimension for Design Specifications¶
*Resistor: Body Size:4.0±0.5 mm x 11.0±1.0 mm; *Battery pack: 7.28 x 5.75 x 2.56 inches *Screws: Size (L x Dia.): approx. 5 x 2.8mm *IR distance sensor: board size: 3.2CM * 1.4CM *TIP transistor: 9.15 x 10.4 x 4.6mm *Pouch: Capacity: 1.75 fluid ounces, Spout Inner Dia 0.32”, Size: 2 3/4”W x 4”H x 1 1/2”D *Motor length : 4.5cm , width: 2.5cm
